Integrated Servo / Smart Drive Unit

Integrated motor, drive, control, and feedback unit for switchgear mechanisms, remote operation, position control, and OEM motion modules.

Key Range

Technical Datasheets

Item	Data
Product name	Integrated Servo / Smart Drive Unit
Product type	Project-based integrated motion control unit
Main function	Motor drive, control logic, feedback, and mechanical output in one unit
Motion direction	Rotary, limited-angle rotary, or linear motion by project
Motor direction	Servo motor, PMSM, BLDC, or custom motor by design
Drive structure	Integrated drive electronics or matched control board
Control modes	Position, speed, torque, jog, homing, open / close, reset, or program logic
Feedback options	Encoder, limit switch, Hall signal, position sensor, travel confirmation
Communication options	I/O, pulse, RS485, CANopen, EtherCAT, Modbus, or project protocol
Mechanical output	Shaft, flange, gear output, linkage interface, or custom actuator interface
Holding options	Brake, mechanical lock, magnetic holding, or project safety design
Protection review	Voltage, current, overload, overheat, stall, limit position, fault feedback
Best fit	High-voltage switchgear operating mechanisms, spring charging units, disconnectors, remote switching devices, test fixtures, compact automation modules, and OEM actuator systems

Configuration Direction	Main Use	Key Confirmation
Integrated Servo Drive Unit	Compact smart motion control	Voltage, power, torque, feedback, control mode
Geared Servo Actuator Unit	Lower speed and higher output torque	Reducer ratio, output shaft, backlash, holding need
Switchgear Operating Unit	Opening, closing, charging, reset, or remote operation	Stroke, angle, operating time, interlock, limit position
Limited-Angle Rotary Unit	Defined rotation angle or switching movement	Output angle, stop position, speed curve, torque curve
Linear Actuation Unit	Push-pull or travel movement	Stroke, thrust, speed, guide structure, sensor feedback
OEM Custom Smart Drive	Machine-specific drive module	Drawing, connector, housing, program, communication protocol

Is Integrated Servo / Smart Drive Unit the same as SMQ340?

No. SMQ340 is a known smart geared motor platform mainly tied to ceramic and conveyor applications. Integrated Servo / Smart Drive Unit is a broader servo-integrated smart drive product direction that requires model confirmation.

Is it the same as SV200 frequency converter?

No. SV200 is a standalone frequency converter used to control a separate motor or geared motor. Integrated Servo / Smart Drive Unit combines more drive-related functions into one compact unit or configuration path.

Is it the same as PMSM?

No. PMSM is the motor. Integrated Servo / Smart Drive Unit is a motor-drive-control configuration direction that may include motor, drive, communication, feedback, and mechanical installation review.

Does this product support position control?

Position control can be reviewed when the selected configuration supports feedback and servo-oriented control. Encoder, communication, load inertia, motion profile, and parameter setup should be confirmed before quotation.

Does it support communication with PLC or host systems?

Communication can be reviewed as part of the configuration. Protocol, wiring, terminal definition, host system, and commissioning requirements should be confirmed before model selection.

Can it replace a separate motor + drive + gearbox system?

It can be reviewed for retrofit projects when the existing motor, drive, gearbox, wiring layout, control cabinet, speed range, torque, mounting, and communication requirements are available.

Can it be used with a gearbox?

Yes. It can be reviewed with compact geared motor or right-angle geared motor platforms when the ratio, output speed, torque, mounting, and shaft connection are confirmed.

What information is needed before quotation?

Send application equipment, control mode, speed, torque, motor power, voltage, communication requirement, feedback requirement, brake requirement, mounting form, cable outlet, working environment, and existing system photos if it is a retrofit.

Can Starshine provide wiring and parameter support?

Wiring diagrams, parameter guides, communication documents, and mechanical drawings can be requested after the selected integrated drive configuration and control requirement are confirmed.
